Key Features
Features
20 F (16 C) temperature drop
Minimal pressure loss
Direct fit for the 2015-2021 STI
This oil cooler kit retains the use of your stock liquid to liquid oil cooler unit
The Subaru STI provides a great balance of power, handling, and reliability. As with any vehicle, controlling fluid temperatures will ensure consistent power and engine longevity.
The Mishimoto Subaru STI Oil Cooler Kit was developed specifically for the 2015-2021 STI and is a great addition to any street or track-driven vehicle. A large Mishimoto 19-row cooler mounts in the front bumper to provide optimal airflow and cooling efficiency. The included direct-fit mounting brackets and preassembled stainless steel lines with -10AN fittings will ensure an easy and hassle-free installation.
This Mishimoto cooler is proven to reduce oil temperatures by 20+°F (16+°C) while maintaining minimal pressure loss. For further heat protection, this Mishimoto Subaru Oil Cooler Kit includes thermal reflective wrap for the oil lines, providing substantial heat deflection from the nearby exhaust. The Mishimoto Subaru STI Oil Cooler Kit can be customized to meet your needs with either a Sleek Silver or Stealth Black cooler and your choice of the Mishimoto Oil Sandwich Plate or the Thermostatic Oil Sandwich Plate. As with all our products, this kit includes the Mishimoto Lifetime Warranty.Please note: Mishimoto fully inspects and cleans all products prior to packaging. However, it is recommended that customers flush the oil cooler with one quart of clean oil prior to installation to remove any debris accumulated during shipping. Please feel free to contact us at support@mishimoto.com if you have any questions.
Read more
TECH SPECS
More Information
Rows
19
Core Length (in)
11
Core Height (in)
5.43
Core Thickness (in)
1.97
Engine Codes
EJ257
Chassis Codes
VA
Installation Notes
Recommended torque specification for all straight fittings and banjo bolts: 15-25 lb-ftDo not exceed the maximum torque rating of 35 ft-lb
Caution
It is the installer's responsibility to check all thermostat plugs, NPT plugs, line fittings, and other connections to assure they are fully tightened before operating the vehicle. Mishimoto recommends that you check all connections at regular intervals, especially during the first few miles after installation. For additional technical information, contact our customer experience team.
Note
Recommended torque specification for all straight fittings and banjo bolts: 15-25 ft-lbDo not exceed the maximum torque rating of 35 ft-lb.
This oil cooler kit will only work with models with the single scroll turbo and un-equal length exhaust manifold. Models with a twin scroll turbo and equal length exhaust manifold may not be compatible with this oil cooler kit.
It is the installer's responsibility to check all thermostat plugs, NPT plugs, line fittings, and other connections to assure they are fully tightened before operating the vehicle. Mishimoto recommends that you check all connections at regular intervals, especially during the first few miles after installation. For additional technical information, please contact our customer experience team.
Purchase Includes
Application-Specific Mounting Brackets 19-Row Oil Cooler 3.5-ft Stainless Steel Braided Hose with 150 -10AN Fittings 4-ft Stainless Steel Braided Hose with 90 and 150 -10AN Fittings M20 Sandwich Plate M20 Stainless Steel Sandwich Plate Adapter M20 x -10AN Straight Fittings Mounting Hardware Set Mishimoto Lifetime Warranty
Note:
Recommended torque specification for all straight fittings and banjo bolts: 15-25 ft-lbDo not exceed the maximum torque rating of 35 ft-lb.
This oil cooler kit will only work with models with the single scroll turbo and un-equal length exhaust manifold. Models with a twin scroll turbo and equal length exhaust manifold may not be compatible with this oil cooler kit.
It is the installer's responsibility to check all thermostat plugs, NPT plugs, line fittings, and other connections to assure they are fully tightened before operating the vehicle. Mishimoto recommends that you check all connections at regular intervals, especially during the first few miles after installation. For additional technical information, please contact our customer experience team.
Warranty
Mishimoto Automotive (“Mishimoto”) warrants its products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorized dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.
For our complete warranty policy, please click here.
