Performance Oil Cooler, fits BMW M5/M6 2012+
MISHI POINTS INFO
Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
- Direct fit for 2012+ BMW M5/M6 models
- CNC-machined billet-aluminium end tanks provide improved durability over stock stamped tanks
- Robust bar-and-plate core resists damage from road debris and provides optimal cooling efficiency
- 24% increase in core volume over stock for improved cooling capacity
- 40% increase in external fin area provides improved heat transfer during extreme driving conditions
- Precision CNC-machined inlet and outlet prevent leaks
- Includes new OEM-quality oil line O-rings for easy installation
- Durable silver powder coated finish prevents corrosion
- Patent Pending
- Mishimoto Lifetime Warranty
Installation Difficulty: Easy
- Direct fit for 2012+ BMW M5/M6 models
- CNC-machined billet-aluminium end tanks provide improved durability over stock stamped tanks
- Robust bar-and-plate core resists damage from road debris and provides optimal cooling efficiency
- 24% increase in core volume over stock for improved cooling capacity
- 40% increase in external fin area provides improved heat transfer during extreme driving conditions
- Precision CNC-machined inlet and outlet prevent leaks
- Includes new OEM-quality oil line O-rings for easy installation
- Durable silver powder coated finish prevents corrosion
- Patent Pending
- Mishimoto Lifetime Warranty
Product Description
The Mishimoto S63 M5/M6 oil cooler features extremely precise CNC-machined billet-aluminium end tanks which are professionally TIG-welded to our robust bar-and-plate core. Our strategically designed 55mm-thick core provides a massive 24% increase in core volume, and a 40% increase in external fin surface area. This added surface area promotes greater heat transfer, which directly impacts internal fluid temperatures. Our performance oil cooler is a complete bolt-on solution that includes everything needed for an easy installation such as hardware and replacement O-rings for the oil lines. Our heat exchanger is finished in a durable silver powder coat, providing both corrosion resistance and improved aesthetics.
Whether your M5 sees frequent track time or just the occasional back-road jaunt, upgrading the oil cooler is a great way to extend the life of your S63 and ensure maximum engine output when you need it most. As with all our BMW products, this oil cooler includes our signature Mishimoto Lifetime Warranty.
TECH SPECS
| Rows | 1 |
|---|---|
| Core Length (in) | 21.5 |
| Core Height (in) | 5.8 |
| Core Thickness (in) | 2.16 |
| Engine Codes | S63 |
| Chassis Codes | F10 F90 |
| Caution | It is the installer's responsibility to check all thermostat plugs, NPT plugs, line fittings, and other connections to assure they are fully tightened before operating the vehicle. Mishimoto recommends that you check all connections at regular intervals, especially during the first few miles after installation. For additional technical information, contact our customer experience team. |
| Overall Height (in) | 2.95 |
| Overall Length (in) | 24 |
| Overall Width (in) | 2.36 |
| Applications | BMW M5 V8 (4.4) 2012-2020 BMW M6 V8 (4.4) 2012-2020 BMW M850i V8 (4.4) 2019-2020 |
Purchase Includes
Performance Oil Cooler
Mounting Bracket Grommets
Oil Line Connection M8 X 1.25 Bolts
Oil Line O-rings
Mishimoto Lifetime Warranty
The executive level is cut-throat. It's always portrayed as a world full of like-minded, power-hungry individuals desperately looking to get ahead of their fellow man. Every achievement is paraded as a victory over others, and everyone has a weakness that's exploited. While this might be more of Hollywood's representation of the corporate world's upper crust, the performance executive segment is that competitive. Auto manufacturers have been duking it out for decades to climb the ladder of the segment that BMW practically invented with the M5. Now in its sixth generation, the progenitor of physics-defying luxury sports cars has a weakness open for exploitation in the form of mismanaged oil temperatures and a vulnerably mounted oil cooler. Luckily we're already on a mission to reinforce this weak link.
The big BMW M's, like the F1X M5 and M6, are the young executives of the automotive world. They're powerful yet hungry for more. They're decisive and maneuver with precision, but most importantly, they're cool under pressure. Sometimes though, they can lose their cool, and for the M5s and M6s of this era, the oil cooler tends to be the source of their undoing. Luckily, we've already started on our plan to help the F1X's keep climbing the performance ladder.
Before we dig into our plans to improve the M5's oil cooler, let's take a look at the OEM cooler. BMW engineers are masters of packaging. Effective use of space is the name of the game, and when it comes to fitting the array of coolers on the front of their powerhouse sedans. In the case of the oil cooler, the engineers mounted this heat exchanger horizontal and right at the edge of the M5's big-mouthed fascia and perpendicular with the rest of the cooling stack. This mounting method means that the cooler effectively utilizes the
