The Mishimoto performance aluminium radiator for the Nissan Skyline is designed and engineered to maximize cooling efficiency by up to 30%, boost engine functions, and most importantly protect your car from overheating. Whether you drive your vehicle daily or take it for track runs. The Mishimoto aluminium Nissan Skyline radiator features a lightweight dual core, 100% brazed aluminium, and polished end tanks, enhancing the overall performance of your engine. Every Mishimoto aluminium radiator is a direct OEM fit, making installation effortless with no cutting or modification required, the ideal upgrade to the stock Nissan Skyline radiator. All Mishimoto radiators come with a high pressure 1.3 bar Mishimoto radiator cap and, as with every Mishimoto aluminium radiator, this radiator includes the Mishimoto Lifetime Warranty. A perfect match to the Mishimoto lightweight aluminium Nissan Skyline fan shroud kit for the R32.
Model:
MMRAD-RHD-R32
Performance Aluminium Radiator fits Nissan Skyline R32
โฌ320.00
Installation Difficulty:
Medium
MISHI POINTS INFO
Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
Installation Specs
Medium
DIFFICULTY
3 Parts
PARTS INCLUDED
- • Mishimoto Radiator
- • Mishimoto Radiator Cap
- • Magnetic Drain Plug
- • Mishimoto Lifetime Warranty
1 Resource
INSTALL DOCS
Key Benefits
- Two-row, 1.25-inch thick efficient brazed aluminium core provides increased fluid capacity and optimal heat dissipation โ built for street and track use in the Nissan Skyline R32.
- Full aluminium construction with TIG-welded end tanks delivers efficient temperature reduction for stock and modified R32 builds across both street and track environments.
- 1.3 bar high-pressure radiator cap and Magnetic Drain Plug included โ raises the coolant boiling point and captures harmful metallic debris, no additional hardware needed.
- Full aluminium end tanks with TIG-welded construction replace the factory plastic-tank components that crack under the heat cycling of RB-series turbocharged engines.
- Two-row brazed aluminium core efficiently transfers thermal energy into the airstream, keeping R32 coolant temps stable during back-to-back track sessions.
- Confirmed direct fit for the 1989โ1993 Nissan Skyline R32 โ no cutting, fabricating, or adapter work required.
- Efficient temperature regulation handles the thermal demands of stock and modified R32 builds, including upgraded boost and high-output RB-series setups.
- Own it for life โ backed by Mishimoto's Lifetime Warranty, your investment is protected long after install day.
Key Benefits
- Two-row, 1.25-inch thick efficient brazed aluminium core provides increased fluid capacity and optimal heat dissipation โ built for street and track use in the Nissan Skyline R32.
- Full aluminium construction with TIG-welded end tanks delivers efficient temperature reduction for stock and modified R32 builds across both street and track environments.
- 1.3 bar high-pressure radiator cap and Magnetic Drain Plug included โ raises the coolant boiling point and captures harmful metallic debris, no additional hardware needed.
- Full aluminium end tanks with TIG-welded construction replace the factory plastic-tank components that crack under the heat cycling of RB-series turbocharged engines.
- Two-row brazed aluminium core efficiently transfers thermal energy into the airstream, keeping R32 coolant temps stable during back-to-back track sessions.
- Confirmed direct fit for the 1989โ1993 Nissan Skyline R32 โ no cutting, fabricating, or adapter work required.
- Efficient temperature regulation handles the thermal demands of stock and modified R32 builds, including upgraded boost and high-output RB-series setups.
- Own it for life โ backed by Mishimoto's Lifetime Warranty, your investment is protected long after install day.
| Overall Length (in) | 19.7 |
|---|---|
| Overall Height (in) | 26.2 |
| Overall Width (in) | 1.75 |
| Core Length (in) | 14.96 |
| Core Height (in) | 25.59 |
| Core Thickness (in) | 1.25 |
| Fluid Capacity (gal) | 2.69 |
| Rows | 2 |
| Inlet (in) | 1.4 |
| Outlet (in) | 1.4 |
| Drain Plug Thread Size | M12 x 1.5 |
| Engine Codes | RB20DET RB26DETT |
| Chassis Codes | R32 |
| Note | This item is for Manual Transmission vehicles. For automatic applications, please purchase optional Mishimoto Universal Transmission Cooler Kit. Compatible with OEM and Mishimoto Radiators. This product will not fit HICAS model GT-Rs. |
| Coolant Capacity | 2.69 |
Mishimoto Radiator
Mishimoto Radiator Cap
Magnetic Drain Plug
Mishimoto Lifetime Warranty
Mishimoto Radiator Cap
Magnetic Drain Plug
Mishimoto Lifetime Warranty
