Every Mishimoto race aluminium radiator is designed and engineered to maximize cooling efficiency, boost engine functions, and most importantly, protect your car from overheating on and off the track. Lightweight, made from 100% brazed aluminium, and cast end tanks TIG-welded for increased durability, Mishimoto race radiators will enhance the overall performance of your engine. Like all Mishimoto aluminium radiators, this race aluminium radiator comes with the signature Mishimoto Lifetime Warranty.
Model:
MMRAD-STI-08
Mishimoto 21.8" x 28.0" Single Pass 2-Row Race Aluminium Radiator
€333.10
Sale Price
Regular Price
Installation Difficulty:
Medium
MISHI POINTS INFO
Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
Key Features
- Lightweight
- Full aluminium construction including durable, TIG-welded end tanks
- Features a two-row, 1.65" thick, efficient brazed aluminium core
- Increased fluid capacity and optimal heat dissipation
- Provides efficient temperature reduction for use on the street, track, rallycross, or autocross course
- Includes 1.3 Bar High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system
- Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
- Mishimoto Lifetime Warranty
Key Features
- Lightweight
- Full aluminium construction including durable, TIG-welded end tanks
- Features a two-row, 1.65" thick, efficient brazed aluminium core
- Increased fluid capacity and optimal heat dissipation
- Provides efficient temperature reduction for use on the street, track, rallycross, or autocross course
- Includes 1.3 Bar High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system
- Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
- Mishimoto Lifetime Warranty
| Overall Length (in) | 21.8 |
|---|---|
| Overall Height (in) | 28 |
| Overall Width (in) | 2.15 |
| Core Length (in) | 13.39 |
| Core Height (in) | 27.08 |
| Core Thickness (in) | 1.65 |
| Rows | 2 |
| Inlet (in) | 1.54 |
| Outlet (in) | 1.54 |
| Drain Plug Thread Size | M12 x 1.5 |
| Coolant Capacity | 2.21 |
Mishimoto Radiator
Mishimoto Radiator Cap
Overflow Nipples - 2
Magnetic Drain Plug
Mishimoto Lifetime Warranty
Mishimoto Radiator Cap
Overflow Nipples - 2
Magnetic Drain Plug
Mishimoto Lifetime Warranty
