Key Features
Features
Direct fit for the 2006-2012 Mazdaspeed 3
Single can mounts in line with the PCV system to separate oil from air using a 50-micron bronze filter
Helps reduce carbon build-up on intake valves
Billet 6061 aluminium sealed can sealed with Viton™ O-rings
Installs in under 30 minutes
Robust, application-specific bracket mounts the can in a serviceable location
Includes pre-molded hoses for simplified installation
Integrated check valve prevents leaks by keeping boost pressure from reaching the catch can and crankcase.
Defends intake system and essential engine components from oil blow-by
CNC-machined aluminium barbed fittings ensure a sturdy connection between lines and can
Catch can has a 7.5 oz. capacity for longer serving intervals
Internal air diverter increases air turbulence to improve oil separation
Helps maintain proper octane levels to reduce potential detonation
Add a layer of protection to your 2006-2012 Mazdaspeed 3 with the Mishimoto Baffled Oil Catch Can Kit. The MS3 might have been one of the pioneers in the North American hot-hatch movement, but like the rest of the direct-injected turbocharged engines of that era, it suffers from copious carbon buildup due to engine blow-by. The 2.3L MZR turbo has a unique issue with blow-by. It's equipped with a top-mounted intercooler, which is prone to heat-soak, effectively baking all of the oil and fuel droplets into the heat exchanger. With the Mishimoto Baffled Oil Catch Can Kit, those crankcase gases are intercepted before even reaching the intercooler. We also included our taller 7.5oz catch can to compensate for the increased levels of blow-by that the Mazdaspeed 3 experiences in colder weather. Also included in the kit are pre-formed hoses to ensure a simple and direct fit in your MS3. As with all of our products, the Mazdaspeed 3 Baffled Oil Catch Can Kit is covered under the Mishimoto Lifetime Warranty, keeping your 2.3L MZR Turbo blow-by free over the lifetime of the car.
Read more
TECH SPECS
More Information
Applications
2007-2013 Mazdaspeed 3
Installation Notes
22 in-lbs (2.5NM) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in- 2-3NM. Do not exceed the maximum torque rating of 27 in-lbs (3NM).
Note
After installation, Mishimoto recommends checking the contents of the baffled catch cans every 500 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
(1) Large Baffled Oil Catch Can (1) Application Specific Mounting Bracket (2) Direct-Fit Hoses with Integrated Check Valve (4) Worm-Gear Clamps (2) 1/2-in Aluminum Barbed Fittings Mounting Hardware Mishimoto Lifetime Warranty
Note:
After installation, Mishimoto recommends checking the contents of the baffled catch cans every 500 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
