Direct fit for the 1970–1973 Datsun 240Z and 1974–1975 Datsun 260Z|Full aluminium design with durable, TIG-welded construction|Features a two-row, 1.65" thick brazed aluminium core, providing ideal fluid temperatures on the street or track|Ideal replacement for an aged, clogged, or leaking stock radiator|Includes 1.3 Bar High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system|Includes Magnetic Drain|Plug to capture any metallic debris/fragments in your cooling system|Mishimoto Lifetime Warranty


The Mishimoto performance aluminium radiator for the Datsun 240Z is the ideal update to the stock Datsun radiator. The last thing you want is to be limited by an old, worn out radiator during a hot day at the strip or when you're stuck in traffic. Our engineers know that, and our design reflects this by utilizing all-aluminium construction and added fluid capacity to increase cooling efficiency. With polished end tanks and a signature Mishimoto radiator cap, the Mishimoto Datsun 240Z radiator looks as good as it performs!

Purchase Includes

Mishimoto Radiator--Mishimoto Radiator Cap--Magnetic Drain Plug--Mishimoto Lifetime Warranty
More Information
Overall Height (in)27.3
Overall Length (in)19.16
Overall Width (in)6.2
Core Length (in)23.15
Core Height (in)13.58
Fluid Capacity (gal)2.39
Inlet (in)1.38
Outlet (in)1.38
Core Thickness (in)1.65
Drain Plug Thread SizeM12 x 1.5
Applications1970-1973 Datsun 240Z--1974-1975 Datsun 260Z
Engine CodesL24--L26
Chassis CodesS30
Coolant Capacity2.39
Download Installation Guide
(Size: 1.6 MB)
Installation Guides
