Performance Aluminium Radiator, fits Toyota Tacoma 2.7L/4.0L 2005-2015 PRE-SALE
MISHI POINTS INFO

Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
- Direct fit for 2005-2015 Toyota Tacoma with 2.7L/4.0L
- All-aluminum design with precision TIG-welded end tanks
- Features two-row 1.65-in core with strategically designed fins for maximum cooling efficiency
- 47-percent increase in core volume
- 84-percent increase in external fin surface area for greater heat transfer
- 53-percent improvement in heat rejection
- Efficient in-tank transmission cooler ensures optimal transmission fluid temperatures
- Includes Mishimoto Magnetic Drain Plug to capture metallic debris within the cooling system
- Mishimoto Lifetime Warranty
- Note: Coupons and discounts do not apply to items in pre-sale
Key Features
- Direct fit for 2005-2015 Toyota Tacoma with 2.7L/4.0L
- All-aluminum design with precision TIG-welded end tanks
- Features two-row 1.65-in core with strategically designed fins for maximum cooling efficiency
- 47-percent increase in core volume
- 84-percent increase in external fin surface area for greater heat transfer
- 53-percent improvement in heat rejection
- Efficient in-tank transmission cooler ensures optimal transmission fluid temperatures
- Includes Mishimoto Magnetic Drain Plug to capture metallic debris within the cooling system
- Mishimoto Lifetime Warranty
| Overall Length (in) | 30.9 |
|---|---|
| Overall Height (in) | 22.2 |
| Overall Width (in) | 2.2 |
| Core Length (in) | 25.6 |
| Core Height (in) | 21.4 |
| Core Thickness (in) | 1.65 |
| Rows | 2 |
| Inlet (in) | 1.38 |
| Outlet (in) | 1.38 |
| Applications | Toyota Tacoma I4 (2.7) 2005-2015 Toyota Tacoma V6 (4.0L) 2005-2015 |
| Engine Codes | 2TR-FE 1GR-FE |
| Chassis Codes | N220 N240 N250 N260 N270 |
Mishimoto Lifetime Warranty
Mishimoto Automotive (“Mishimoto”) warrants its products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorized dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.
For our complete warranty policy, please click here.
